35YXJ220M8X11.5 Datasheet PDF - Rubycon

Manufacturer:

Rubycon

Category:

Single Capacitors

Case Package:

8*12

Description:

220uF ±20% 35V 640mA(105℃&100kHz) Φ8mm

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

35YXJ220M8X11.5 Datasheet PDF (2 Pages)

View Datasheet

Click page to view the detail

35YXJ220M8X11.5 Specifications

TYPE

DESCRIPTION

Mounting Style

Through Hole

Voltage Rating (DC)

35 V

Capacitance

220 µF

Capacitance Tolerance

±20 %

Case/Package

8*12

Ripple Current

640 mA

Operating Temperature (Max)

105 ℃

Operating Temperature (Min)

-40 ℃

Voltage Rating

35 V

35YXJ220M8X11.5 Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Active

Packaging

Bulk

Size-Height

11.5 mm

Size-Diameter

Φ8mm

Operating Temperature

-40℃ ~ 105℃

Minimum Packing Quantity

2000

Life (Hours)

7000 h

35YXJ220M8X11.5 Environmental

35YXJ220M8X11.5 Function Overview

35YXJ220M8X11.5 Documents

35YXJ220M8X11.5 Other Datasheet PDF

Rubycon

2 Pages / 0.14 MByte

35YXJ220M8 Documents

35YXJ220M8X11.5 Datasheet PDF

Rubycon

220uF ±20% 35V 640mA(105℃&100kHz) Φ8mm
