4608X-102-272LF Datasheet PDF - Bourns J.W. Miller

Manufacturer:

Bourns J.W. Miller

Category:

Resistor Arrays

Case Package:

SIP-8

Description:

Array/Network Resistor, Isolated, Metal Glaze/thick Film, 1W, 2700Ω, 100V, 2% +/-Tol, 100ppm/Cel, Through Hole Mount, 8010, SIP, ROHS COMPLIANT

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

4608X-102-272LF Datasheet (2 Pages)

4608X-102-272LF Datasheet PDF (2 Pages)

View Datasheet

Click page to view the detail

4608X-102-272LF Specifications

TYPE

DESCRIPTION

Number of Contacts

8 Contact

Mounting Style

Through Hole

Number of Pins

8 Pin

Voltage Rating (DC)

100 V

Insulation Resistance

10.0 MΩ

Capacitance Tolerance

±2 %

Case/Package

SIP-8

Power Rating

1 W

Number of Positions

8 Position

Resistance

2.7 kΩ

Resistance Tolerance

±2 %

Operating Temperature (Max)

125 ℃

Operating Temperature (Min)

-55 ℃

Voltage Rating

100 V

View Datasheet >

4608X-102-272LF Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Active

Packaging

Bulk

Size-Length

20.27 mm

Size-Width

2.49 mm

Size-Height

5.08 mm

Lead Length

3.43 mm

Operating Temperature

-55℃ ~ 125℃

Size-Thickness

2.49 mm

Temperature Coefficient

±100 ppm/℃

View Datasheet >

4608X-102-272LF Environmental

4608X-102-272LF Export Classifications

4608X-102-272LF Function Overview

4608X-102-272LF Documents

4608X-102-272LF Datasheet

Bourns J.W. Miller

2 Pages / 0.2 MByte

4608X-102-272LF Other Datasheet PDF

Bourns J.W. Miller

23 Pages / 2.89 MByte

4608X102272 Documents

4608X-102-272 Datasheet PDF

Bourns J.W. Miller

Res Thick Film NET 2.7KΩ 2% 1W ¦100ppm/¦C ISOL 8Pin SIP Pin Thru-Hole Bulk

4608X102272 Datasheet PDF

Bourns J.W. Miller

4608X-102-272LF Datasheet PDF

Bourns J.W. Miller

Array/Network Resistor, Isolated, Metal Glaze/thick Film, 1W, 2700Ω, 100V, 2% +/-Tol, 100ppm/Cel, Through Hole Mount, 8010, SIP, ROHS COMPLIANT

4608X-102-272FLF Datasheet PDF

Bourns J.W. Miller

Res Thick Film NET 2.7KΩ 1% 1W ±100ppm/℃ ISOL Conformal 8Pin SIP Pin Thru-Hole Bulk

4608X-102-272F Datasheet PDF

Bourns J.W. Miller

Res Thick Film NET 2.7KΩ 1% 1W ±100ppm/℃ ISOL Conformal Coated 8Pin SIP Pin Thru-Hole Bulk

4608X102272LF Datasheet PDF
