Part Datasheet Search > LED Arrays/Light Bars/Bar Graphs > Dialight > 550-2207F Datasheet PDF
550-2207F
$ 0.416

550-2207F Datasheet PDF - Dialight

Manufacturer:
Dialight
Category:
LED Arrays/Light Bars/Bar Graphs
Description:
550 Series Green Ø 5mm 65° 10mcd 25mA 2.1V LED Circuit Board Indicator
Pictures:
3D Model
Symbol
Footprint
Pinout
Product Pictures
Documentation:
550-2207F Datasheet (15 Pages)
Package Outline Dimension on14 Page
550-2207F Datasheet PDF (15 Pages)
View Datasheet
Click page to view the detail

550-2207F Specifications

TYPE
DESCRIPTION
Mounting Style
Through Hole
Number of Pins
2 Pin
Number of Positions
2 Position
Forward Voltage
2.1 V
Wavelength
563 nm
Luminous Intensity
10 mcd
Viewing Angle
65°
Lens Type
Diffused
Peak Wavelength
563 nm
Power Dissipation
75 mW
Test Current
10 mA
Forward Current
10 mA
Maximum Forward Voltage (Max)
3 V
Forward Current (Max)
25 mA
Operating Temperature (Max)
85 ℃
Operating Temperature (Min)
-25 ℃
Power Dissipation (Max)
75 mW
Voltage Rating
2.1 V
View Datasheet >

550-2207F Documents

550-2207F Datasheet
Dialight
15 Pages / 0.23 MByte
550-2207F Other Datasheet PDF
Dialight
12 Pages / 0.08 MByte
550-2207F Drawing Diagrams
Dialight
1 Pages / 0.09 MByte
550-2207F Notice File
Dialight
1 Pages / 0.02 MByte

5502207 Documents

550-2207 Datasheet PDF
Dialight
LED 5MM RT ANG HI EFF GRN PC MNT
5502207 Datasheet PDF
Dialight
LED 5MM RT ANG HI EFF GRN PC MNT
550-2207F Datasheet PDF
Dialight
550 Series Green Ø 5mm 65° 10mcd 25mA 2.1V LED Circuit Board Indicator
5502207F Datasheet PDF
Dialight
LED Uni-Color Green 563nm 2Pin Bulk
5502207811F Datasheet PDF
Dialight
LED Uni-Color Green 2Pin
550-2207-004F Datasheet PDF
Dialight
LED 5MM QUAD HI EFF GREEN PC MNT
550-2207-100F Datasheet PDF
Dialight
LED Uni-Color Green 563nm 2Pin Bulk
550-2207-002F Datasheet PDF
Dialight
LED Uni-Color Green 563nm 4Pin
550-2207-811F Datasheet PDF
Dialight
LED Uni-Color Green 2Pin
550-2207-810F Datasheet PDF
Dialight
Led Cbi 5mm Green Diffused Ra
