796636-2
$ 0.357

796636-2 Datasheet PDF - TE Connectivity

Manufacturer:
TE Connectivity
Category:
Terminal Blocks
Case Package:
300
Description:
BUCHANAN - TE CONNECTIVITY 796636-2 Terminal Block, Eurostyle, Header, 5.08mm, 2Positions, 15A, 300V, Through Hole Vertical
Pictures:
3D Model
Symbol
Footprint
Pinout
Product Pictures
Documentation:
796636-2 Datasheet (6 Pages)796636-2 Application Note (8 Pages)
796636-2 Datasheet PDF (6 Pages)
View Datasheet
Click page to view the detail

796636-2 Specifications

TYPE
DESCRIPTION
Number of Contacts
2 Contact
Gender
Male
Mounting Style
Through Hole
Contact Plating
Tin
Current Rating
15 A
Case/Package
300
Number of Rows
1 Row
Pin Pitch
5.08 mm
Orientation
Straight
Flammability Rating
UL 94 V-0
Number of Positions
2 Position
Current Rating (Max)
15A/触头
Operating Temperature (Max)
105 ℃
Operating Temperature (Min)
-40 ℃
Voltage Rating (Max)
300 VAC
Voltage Rating
300 VAC
View Datasheet >

796636-2 Size & Package

TYPE
DESCRIPTION
Product Lifecycle Status
Active
Housing Color
Green
Packaging
Box
Color
Green
Contact Material
Phosphor Bronze
Material
Nylon
Size-Length
11.98 mm
Size-Width
8.35 mm
Size-Height
12 mm
Operating Temperature
-40℃ ~ 110℃
Housing Material
Nylon 6/6
View Datasheet >

796636-2 Documents

796636-2 Datasheet
TE Connectivity
6 Pages / 0.43 MByte
796636-2 Other Datasheet PDF
TE Connectivity
2 Pages / 0.07 MByte
796636-2 Drawing Diagrams
TE Connectivity
3 Pages / 0.15 MByte
796636-2 Application Note
TE Connectivity
8 Pages / 0.29 MByte
796636-2 Product Catalog
TE Connectivity
109 Pages / 26.9 MByte
796636-2 Other References
TE Connectivity
1 Pages / 0.18 MByte
