CSD97396Q4MT Datasheet PDF - TI

Manufacturer:

Category:

FET Drivers

Case Package:

VSON EP-8

Description:

Conv DC-DC Single Step Down 4.5V 24V 8Pin VSON T/R

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

CSD97396Q4MT Datasheet (20 Pages)

Pinout Diagram on3 PageHot

Package Outline Dimension on18 Page

CSD97396Q4MT Datasheet PDF (20 Pages)

View Datasheet

Click page to view the detail

CSD97396Q4MT Specifications

TYPE

DESCRIPTION

Mounting Style

Surface Mount

Number of Pins

8 Pin

Supply Voltage (DC)

4.50V (min)

Case/Package

VSON EP-8

Number of Outputs

1 Output

Number of Positions

8 Position

Power Dissipation

8 W

Switching Frequency

2000 kHz

Input Voltage (Max)

24 V

Input Voltage (Min)

4.5 V

Output Current (Max)

30 A

Operating Temperature (Max)

150 ℃

Operating Temperature (Min)

-40 ℃

Power Dissipation (Max)

8000 mW

Supply Voltage

4.5V ~ 5.5V

Supply Voltage (Max)

5.5 V

Supply Voltage (Min)

4.5 V

View Datasheet >

CSD97396Q4MT Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Active

Packaging

Cut Tape (CT)

Operating Temperature

-40℃ ~ 150℃ (TJ)

View Datasheet >

CSD97396Q4MT Environmental

CSD97396Q4MT Function Overview

CSD97396Q4MT Documents

CSD97396Q4MT Datasheet

20 Pages / 0.48 MByte

CSD97396Q4MT Other Datasheet PDF

4 Pages / 0.32 MByte

CSD97396Q4 Documents

CSD97396Q4M Datasheet PDF

Conv DC-DC Single Step Down 4.5V to 24V 8Pin VSON T/R

CSD97396Q4MT Datasheet PDF

Conv DC-DC Single Step Down 4.5V 24V 8Pin VSON T/R
