DD104N16K
$ 115.734

DD104N16K Datasheet PDF - Infineon

Manufacturer:
Infineon
Category:
Schottky Diodes
Case Package:
DD-104
Description:
Diode 1.6kV 104A 3Pin PB20
Pictures:
3D Model
Symbol
Footprint
Pinout
Product Pictures
Documentation:
DD104N16K Datasheet (10 Pages)DD104N16K User Reference Manual Guide (44 Pages)DD104N16K Application Note (84 Pages)
DD104N16K Datasheet PDF (10 Pages)
View Datasheet
Click page to view the detail

DD104N16K Specifications

TYPE
DESCRIPTION
Mounting Style
Screw
Number of Pins
3 Pin
Case/Package
DD-104
Output Current
160 A
Max Forward Surge Current (Ifsm)
2.9 kA
Maximum Forward Voltage (Max)
1.4 V
Forward Current (Max)
104 A
Operating Temperature (Max)
150 ℃
Operating Temperature (Min)
-40 ℃
View Datasheet >

DD104N16K Size & Package

TYPE
DESCRIPTION
Product Lifecycle Status
Active
Packaging
Tray
Size-Length
92 mm
Size-Width
20 mm
Size-Height
30 mm
View Datasheet >

DD104N16K Documents

DD104N16K Datasheet
Infineon
10 Pages / 0.22 MByte
DD104N16K User Reference Manual Guide
Infineon
44 Pages / 2.48 MByte
DD104N16K Other Datasheet PDF
Infineon
73 Pages / 2.93 MByte
DD104N16K Application Note
Infineon
84 Pages / 2.19 MByte

DD104N16 Documents

DD104N16 Datasheet PDF
Eupec
Eupec Infineon power module
DD104N16K Datasheet PDF
Infineon
Diode 1.6kV 104A 3Pin PB20
DD104N16KHPSA1 Datasheet PDF
Infineon
20mm PowerBLOCK Rectifier Diode Modules are designed and assembled with high reliable pressure contact technology us...
DD104N16K-K Datasheet PDF
Infineon
Diode 1.6kV 104A 3Pin PB20
DD104N16K Datasheet PDF
Eupec
Rectifier Diode, 1 Phase, 2 Element, 104A, 1600V V(RRM), Silicon,
DD104N16KOF Datasheet PDF
Infineon
Discrete Semiconductor Modules 1600V 160A
DD104N16K-A Datasheet PDF
Eupec
Rectifier Diode, 1 Phase, 2 Element, 104A, 1600V V(RRM), Silicon,
