EKMG350ELL470ME11D Datasheet PDF - UA(United Automation)

Manufacturer:

UA(United Automation)

Category:

Aluminum Electrolytic Capacitors

Description:

CAP ALUM 47uF 20% 35V RADIAL

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

EKMG350ELL470ME11D Datasheet (3 Pages)

Part Numbering System on1 Page

EKMG350ELL470ME11D Datasheet PDF (3 Pages)

View Datasheet

Click page to view the detail

EKMG350ELL470ME11D Specifications

TYPE

DESCRIPTION

Mounting Style

Through Hole

Capacitance

47 μF

Capacitance Tolerance

±20 %

Pin Pitch

2 mm

Ripple Current

90mA @120Hz

Operating Temperature (Max)

105 ℃

Operating Temperature (Min)

-55 ℃

Voltage Rating

35 V

View Datasheet >

EKMG350ELL470ME11D Environmental

EKMG350ELL470ME11D Documents

EKMG350ELL470ME11D Datasheet

UA(United Automation)

3 Pages / 0.08 MByte

EKMG350ELL470ME11D Other References

UA(United Automation)

1 Pages / 0.1 MByte

EKMG350ELL470ME11 Documents

EKMG350ELL470ME11D Datasheet PDF

Chemi-Con

Cap Aluminum Lytic 47uF 35V 20% (5 X 11mm) Radial 2mm 90mA 1000H 105℃ Bulk

EKMG350ELL470ME11D Datasheet PDF

UA(United Automation)

CAP ALUM 47uF 20% 35V RADIAL
