$ 0.468

EKMG500ELL102MK25S Datasheet PDF - UA(United Automation)

Manufacturer:

UA(United Automation)

Category:

Aluminum Electrolytic Capacitors

Description:

UNITED CHEMI-CON EKMG500ELL102MK25S Electrolytic Capacitor, Miniature, 1000µF, 50V, KMG Series, ± 20%, Radial Leaded, 12.5mm

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

EKMG500ELL102MK25S Datasheet (3 Pages)

Part Numbering System on1 Page

EKMG500ELL102MK25S Datasheet PDF (3 Pages)

View Datasheet

Click page to view the detail

EKMG500ELL102MK25S Specifications

TYPE

DESCRIPTION

Mounting Style

Through Hole

Capacitance

1000 µF

Capacitance Tolerance

±20 %

Pin Pitch

5 mm

Operating Temperature (Max)

105 ℃

Operating Temperature (Min)

-55 ℃

Voltage Rating

50 V

View Datasheet >

EKMG500ELL102MK25S Environmental

EKMG500ELL102MK25S Documents

EKMG500ELL102MK25S Datasheet

UA(United Automation)

3 Pages / 0.08 MByte

EKMG500ELL102MK25 Documents

EKMG500ELL102MK25S Datasheet PDF

Chemi-Con

Cap Aluminum Lytic 1000uF 50V 20% (12.5 X 25mm) Radial 5mm 950mA 1000H 105℃ Bulk

EKMG500ELL102MK25S Datasheet PDF

UA(United Automation)

UNITED CHEMI-CON EKMG500ELL102MK25S Electrolytic Capacitor, Miniature, 1000µF, 50V, KMG Series, ± 20%, Radial Leaded, 12.5mm
