IRLMS6802TRPBF Datasheet PDF - International Rectifier

Manufacturer:

International Rectifier

Category:

MOSFETs

Case Package:

TSOP-6

Description:

MOSFET P-CH 20V 5.6A 6-TSOP

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

IRLMS6802TRPBF Datasheet (2 Pages)

IRLMS6802TRPBF Specifications

TYPE

DESCRIPTION

Mounting Style

Surface Mount

Number of Pins

6 Pin

Voltage Rating (DC)

-20.0 V

Current Rating

-5.60 A

Case/Package

TSOP-6

Polarity

P-Channel

Power Dissipation

2 W

Part Family

IRLMS6802

Drain to Source Voltage (Vds)

20 V

Breakdown Voltage (Drain to Source)

-20.0 V

Continuous Drain Current (Ids)

-5.60 A

Rise Time

33.0 ns

Input Capacitance (Ciss)

1079pF @10V(Vds)

Input Power (Max)

2 W

View Datasheet >

IRLMS6802TRPBF Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Unknown

Packaging

Tape & Reel (TR)

View Datasheet >

IRLMS6802TRPBF Environmental

IRLMS6802TRPBF Documents

IRLMS6802TRPBF Datasheet

International Rectifier

2 Pages / 0.23 MByte

IRLMS6802TRPBF Other Datasheet PDF

International Rectifier

7 Pages / 0.14 MByte

IRLMS6802 Documents

IRLMS6802 Datasheet PDF

International Rectifier

HEXFET, P채널, Vd = -20V, Rds = 0.05Ω, Id = -5.6A, TSOP-6(SOT-23패키지보다 훨씬작은패키지)

IRLMS6802 Datasheet PDF

Infineon

Micro P-CH 20V 5.6A

IRLMS6802 Datasheet PDF

IRF

HEXFET Power MOSFET

IRLMS6802TRPBF Datasheet PDF

Infineon

Micro P-CH 20V 5.6A

IRLMS6802TRPBF Datasheet PDF

International Rectifier

MOSFET P-CH 20V 5.6A 6-TSOP

IRLMS6802TR Datasheet PDF

International Rectifier

MOSFET P-CH 20V 5.6A 6-TSOP

IRLMS6802TR Datasheet PDF

Infineon

Micro P-CH 20V 5.6A

IRLMS6802PBF Datasheet PDF

International Rectifier

Hexfet Power Mosfet
