LM1117T-ADJ Datasheet PDF - National Semiconductor

Manufacturer:

National Semiconductor

Case Package:

TO-220

Description:

LDO Regulator Pos 1.25V to 13.8V 0.8A 3Pin(3+Tab) TO-220 Rail

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

LM1117T-ADJ Datasheet (25 Pages)

Package Outline Dimension on21 Page

Part Numbering System on2 Page

LM1117T-ADJ Datasheet PDF (25 Pages)

View Datasheet

Click page to view the detail

LM1117T-ADJ Specifications

TYPE

DESCRIPTION

Mounting Style

Through Hole

Number of Pins

3 Pin

Case/Package

TO-220

Number of Outputs

1 Output

Output Voltage

1.25V ~ 13.8V

Output Current

800 mA

voltage rating

1.2 V

Input Voltage (Max)

15 V

Input Voltage (Min)

2.6 V

Output Voltage (Max)

13.8 V

Output Voltage (Min)

1.25 V

Output Current (Max)

0.8 A

Operating Temperature (Max)

125 ℃

Operating Temperature (Min)

0 ℃

Accuracy

1 %

Supply Voltage (Max)

13.75 V

Supply Voltage (Min)

1.5 V

Input Voltage

15 V

View Datasheet >

LM1117T-ADJ Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Unknown

Packaging

Rail

Operating Temperature

0℃ ~ 125℃

View Datasheet >

LM1117T-ADJ Environmental

LM1117T-ADJ Function Overview

LM1117T-ADJ Documents

LM1117T-ADJ Datasheet

National Semiconductor

25 Pages / 0.44 MByte

LM1117 Documents

LM1117 Datasheet PDF

National Semiconductor

800mA Low-Dropout Linear Regulator

LM1117IMPX-3.3/NOPB Datasheet PDF

TEXAS INSTRUMENTS LM1117IMPX-3.3/NOPB Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 3.3V/800mA out, SOT-223-4

LM1117MPX-3.3/NOPB Datasheet PDF

TEXAS INSTRUMENTS LM1117MPX-3.3/NOPB Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 3.3V/800mA out, SOT-223-4

LM1117IMP-3.3/NOPB Datasheet PDF

Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 3.3V/800mA out, SOT-223-3

LM1117IMPX-5.0/NOPB Datasheet PDF

TEXAS INSTRUMENTS LM1117IMPX-5.0/NOPB Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 5V/800mA out, SOT-223-3

LM1117MPX-5.0/NOPB Datasheet PDF

Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 5V/800mA out, SOT-223-3

LM1117DTX-3.3/NOPB Datasheet PDF

Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 3.3V/800mA out, TO-252-3

LM1117MP-3.3/NOPB Datasheet PDF

TEXAS INSTRUMENTS LM1117MP-3.3/NOPB Fixed LDO Voltage Regulator, 15V in, 1.2V Dropout, 3.3V/800mA out, SOT-223-3

LM1117IMP-ADJ/NOPB Datasheet PDF

LDO Voltage Regulator, Adjustable, 2.6V to 15V in, 1.2V drop, 1.25V to 13.8V/800mA out, SOT-223-4

LM1117MPX-3.3 Datasheet PDF

LDO Regulator Pos 3.3V 0.8A 4Pin(3+Tab) SOT-223 T/R
