MCUMR25V106M4X5 Datasheet PDF - Multicomp

Manufacturer:

Multicomp

Category:

Aluminum Electrolytic Capacitors

Case Package:

Radial, CAN

Description:

10uF ±20% 25V Φ4mm 5mm

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

MCUMR25V106M4X5 Datasheet (2 Pages)

MCUMR25V106M4X5 Datasheet PDF (2 Pages)

View Datasheet

Click page to view the detail

MCUMR25V106M4X5 Specifications

TYPE

DESCRIPTION

Mounting Style

Through Hole

Number of Pins

2 Pin

Voltage Rating (DC)

25.0 V

Capacitance

10 µF

Capacitance Tolerance

±20 %

Case/Package

Radial, CAN

Pin Pitch

1.5 mm

Part Family

MCUMR

Operating Temperature (Max)

85 ℃

Operating Temperature (Min)

-40 ℃

Voltage Rating

25 V

View Datasheet >

MCUMR25V106M4X5 Size & Package

TYPE

DESCRIPTION

Packaging

Each

Size-Height

5 mm

Size-Diameter

4.00 mm

Dielectric Material

Aluminum Electrolytic

Life (Hours)

1000h @85℃

View Datasheet >

MCUMR25V106M4X5 Environmental

MCUMR25V106M4X5 Function Overview

MCUMR25V106M4X5 Documents

MCUMR25V106M4X5 Datasheet

Multicomp

2 Pages / 0.06 MByte

MCUMR25V106M4X5 Other Datasheet PDF

Multicomp

4 Pages / 0.04 MByte

MCUMR25V106M4 Documents

MCUMR25V106M4X5 Datasheet PDF

Multicomp

10uF ±20% 25V Φ4mm 5mm
