PVZ2A503A01R00 Datasheet PDF - muRata

Manufacturer:

muRata

Category:

Potentiometers

Case Package:

2X2

Description:

Res Carbon Film Trimmer 50KΩ 30% 0.1W(1/10W) 1(Elec)/1(Mech)Turn (2.1 X 2.7 X 2mm) J-Hook SMD T/R

Pictures:

3D Model

Symbol

Footprint

Pinout

Product Pictures

Documentation:

PVZ2A503A01R00 Datasheet (1 Pages)

Part Numbering System on1 Page

PVZ2A503A01R00 Datasheet PDF (1 Pages)

View Datasheet

Click page to view the detail

PVZ2A503A01R00 Specifications

TYPE

DESCRIPTION

Mounting Style

Surface Mount

Case/Package

2X2

Power Rating

0.1 W

Resistance

50 kΩ

Resistance Tolerance

±30 %

View Datasheet >

PVZ2A503A01R00 Size & Package

TYPE

DESCRIPTION

Product Lifecycle Status

Obsolete

Packaging

Cut Tape (CT)

Size-Length

2.70 mm

Size-Width

2.10 mm

Size-Height

2 mm

Weight

11.0 mg

Temperature Coefficient

±500 ppm/℃

View Datasheet >

PVZ2A503A01R00 Environmental

PVZ2A503A01R00 Function Overview

PVZ2A503A01R00 Documents

PVZ2A503A01R00 Datasheet

muRata

1 Pages / 0.03 MByte

PVZ2A503A01R00 Other Datasheet PDF

muRata

6 Pages / 0.12 MByte

PVZ2A503A01R00 Product Catalog

muRata

55 Pages / 1.36 MByte

PVZ2A503A01 Documents

PVZ2A503A01R00 Datasheet PDF

muRata

Res Carbon Film Trimmer 50KΩ 30% 0.1W(1/10W) 1(Elec)/1(Mech)Turn (2.1 X 2.7 X 2mm) J-Hook SMD T/R
